Description
🔌 EPEver Tracer 10415AN – 100 A MPPT Solar Charge Controller (Auto 12/24/36/48 V)
Heavy-duty MPPT charge controller from EPEver’s Tracer‑AN series—built to handle large solar input (up to ~5 kW), with fast tracking and parallel scalability. Reliable and ideal for robust off-grid or hybrid systems.
⚙️ Key Features
-
MPPT tracking efficiency above 99.5%, with DC‑DC conversion efficiency up to 98%. Supports up to 100 A charge current.
-
Auto system voltage recognition: Works with 12 V, 24 V, 36 V, and 48 V systems.
-
Parallelable configuration: Up to 6 units in parallel via PAL-ADP‑50N adapter, for system capacities up to ~30 kW.
-
Multi-battery and load support: Includes three dry‑contact relays for utility/generator control and load management. Built‑in remote temperature/voltage sensors supported.
-
Robust protection features: Over‑charge/discharge, short-circuit, reverse polarity, over-temperature derating, common negative design.
-
Communication & monitoring: Isolated RS485 ports supporting MODBUS and MT50 remote meter compatibility.
-
Durable build: IP20 housing, operates from −25 °C to +60 °C (with thermal de-rating above 45 °C), weight ~7.4 kg.
📏 Technical Summary — Tracer 10415AN
| Specification | Value |
|---|---|
| System Voltage | 12/24/36/48 V Auto |
| Rated Charge Current | 100 A |
| Rated Charge Power | ~1,250 W (12 V); ~2,500 W (24 V); ~3,750 W (36 V); ~5,000 W (48 V) |
| Max PV Voc | 150 V (cold), ~138 V @ 25 °C |
| MPP Voltage Range | (Battery V + 2 V) – (72 V @ 12 V; 144 V @ 48 V system) |
| Self-Consumption | ~98 mA (12 V); ~46 mA (48 V); drops in standby mode |
| Protection Grade | IP20 (indoor use) |
| Weight & Dimensions | ~7.4 kg; 394 × 242 × 143 mm |
| Operating Temp Range | −25 °C to +60 °C (de‑rates above 45 °C) |
📄 Official Datasheet
For complete technical details, including wiring diagrams, accessory add‑ons (e.g. parallel kit), relay functionality, and programming instructions:
