MIDNITE SOLAR | BREAKER 300V 20A | DC Double Pole

⚡ MidNite Solar MNEPV20-300 – 20 A, 300 V DC Breaker (2‑Pole Version)

The MNEPV20-300 is a double-pole hydraulic-magnetic breaker designed for safe protection in solar and energy storage systems. Each pole is rated for 300 V DC, and they are designed to operate together for simultaneous trip. It utilizes MidNite’s robust CBI YA series technology and is compatible with standard DIN-rail mounting.

Key Specifications:

• Rated Voltage: 300 V DC per pole

• Rated Current: 20 A continuous

• Pole Configuration: Double-pole, common trip

• Breaking Capacity: 10,000 A (AIC), suitable for DC environments

• Width: Ultra-compact ~13 mm (~0.5 inches) per pole

• Mounting Type: Standard 35 mm DIN rail

• Construction: Hydraulic-magnetic trip mechanism, polarized design for correct orientation

• Warranty: 5-year manufacturer coverage

• Weight: Approximately 0.35 lbs (~160 g)

Typical Applications:
PCUs, PV combiner boxes, battery bank disconnects, and distributed PV protection systems.
